Build for precision.
The module is coupled with an integrated light sensor and thermally regulated using Peltier elements.
The electronics of the module are state-of-the-art and enable absolutely precise and consistent light output.
Sensor & thermal cooling
High precision electronics
Mathematic light intensity distribution
The module generates a mathematically describable light intensity distribution.
Build for output
The module has a powerful 350W white light LED source with an CRI of 90.
The module has a maximum luminance of up to 8.8 * 10^6 cd/m²
350W LED Modul
High intensity luminance
High lumen output
The module has a maximum luminous flux of up to 7000 lm (lumens) and a maximum luminous intensity of up to 2600 cd (candela).
Technical Specifications
Electrical properties
Power consumption: up to 720W
Input voltage: 48V
Input current: up to 15A
Light source
350W White LED
Correlated color temperature: 6500K
Color rendering index: 90
Light output: up to 20000 lm
Optical properties
Diffusor
Approximately Lambertian light distribution
Light output: up to 7000 lm
Luminance: up to 8,8 * 10^6 cd/mm^2
Lumoínous intensity: up to 2600 cd
Diffusor and Aperture System
Mathematically describeable light intensity distribution
